JUSHA-C820G 8MP Color Diagnostic Display

JUSHA-C820G 8MP/Color/Diagnostic Display Features and Specifications:

DICOM Calibration

The monitor meets the DICOM 3.14 standard and has a dynamic LUT. Therefore, it ensures accurate and stable lesion diagnosis at any brightness, contrast, and color temperature. For more details on DICOM standards, you can visit DICOM Standards.

Integrated Front Sensor

Users can customize the black point, white point, and environmental brightness of the DICOM curve. Additionally, built-in sensors measure display brightness in real-time, automatically adjusting to the best settings and complying with DICOM standards. Learn more about our sensor technology.

JUSHA Qualitas QA Compatible

Users can check and calibrate the monitor themselves, which reduces the effects of panel aging. Consequently, this prolongs the monitor’s lifespan and ensures more accurate images. Discover more about JUSHA Qualitas QA.

Independent Dual Input Setup

You can independently change the image settings for different video sources, such as calibration mode, resolution, and color depth. Thus, different image modes meet various requirements. Check out our video input options.

Ambient Light Adaptive and Compensation

The monitor measures ambient light in real time and adjusts the display accordingly to ensure accurate diagnosis. For further reading on ambient light sensors, visit Ambient Light Sensors.

SmarTouch

Medical image diagnosis often requires high brightness, which can damage eyesight with long-term use. To solve this, we offer a one-key brightening function. You can switch the display brightness between normal and maximum with a simple shortcut key, thereby providing great convenience. Learn more about SmarTouch technology.

X-ray Film View (XFV)

The XFV can increase the monitor’s brightness to its peak value, replacing the traditional Lightbox for film reading and, as a result, increasing work efficiency. Find out more about X-ray Film View.

Specifications

JUSHA-C820G 8MP/Color/Diagnostic Display Specifications:

• Model No: C820G
• Type: IPS
• Backlight: LED
• Diagonal size: 31.5″
• Display area: 697.31(H) × 392.23(V) mm
• Resolution: 3840 × 2160
• Aspect ratio: 16:9
• Pixel Pitch: 0.18159 × 0.18159 mm
• Color Depth: 10 bit
• LUT Depth: 14 bit
• Viewing angles: 178°
• Maximum brightness (typical): 450 cd/m²
• Maximum calibrated brightness: 400 cd/m²
• Default brightness: 380 cd/m²
• Minimum brightness: 200 cd/m²
• Presets: DICOM/GAMMA2.2/GAMMA2.4/CT/MRI-JS/DSA/DSI/BYPASS
• Contrast ratio: 1300:1
• Response time (Ton+Toff): 27 ms
• Qualitas QA: Yes
• Features: SmarTouch, XFV, ABA, ALC, Real-time DICOM calibration
• Video input: DP x 2, DVI x 1
• USB Ports: Upstream USB-B 2.0 x 1, Downstream USB-A 2.0 x 2
• Power input: 24VDC-3.5A
• Typical power: 50 W
• Maximum power: 80 W
• Power saving: < 0.5 W
• Backlight stabilizer: Yes
• Front sensor: Yes
• Ambient light sensor: Yes
• Other sensors: Temperature
• Housing color: Grey
• Dimensions with stand (W x H x D): 731.4 mm × 538.9 mm × 262 mm
• Dimensions without stand (W x H x D): 731.4 mm × 454.2 mm × 65.7 mm
• Net weight with stand: 15.6 ± 0.5 kg
• Net weight without stand: 11.4 ± 0.5 kg
• VESA: 100 x 100 mm
• Certifications: CE, CCC, Energy saving
